BMP71 Label Printer with Quick Charger

BMP71 Label Printer with Quick Charger

Product Highlights

Maximum Label/Tape Width:

2 in

Color Printing Capability:

Single Color

Maximum Labels per Day:

1000

Stand Alone Printing:

PC connected & Stand-alone

Print Resolution:

300 dpi

Print Technology:

Thermal Transfer

Part Number:

BMP71-QC



Overview

The BMP®71 Label Printer is our most versatile labeler for on-the-job printing. It prints on more than 1000 label parts, and has a convenient handle and rechargeable battery.

  • The BMP®71 Printer with Quick Charger allows you to charge the printer in approximately one hour so you can limit down time and increase productivity
  • The top features of the printer include built-in label design wizards, storage space for more than 100,000 label files, and a large, full color screen
  • Print on more than 45 types of premium label materials, including PermaSleeve® wire markers, indoor/outdoor vinyl, polyester pre-sized labels, and more
  • Compatible with M71 series label cartridges;fits BMP®61, TLS 2200® and HandiMark® cartridges with included roll adaptor

Specifications

Key Characteristics

Key Characteristics Catalog Page # 152
Product Number 115160
UPC 662820801856
Applications Barcode Labeling, Cable & Wire Marking, Circuit Board Marking, Facility ID, General & Industrial ID, Healthcare ID, Industrial ID, Laboratory ID, Lockout Tagout Labeling, Plant Maintenance
UOM Kit
Trade Name BMP®71
Brand Name Brady®
Country of Origin Malaysia
HTS Code (Harmonized Tariff Schedule) 8443.32.1050
ECCN (Export Commodity Control Number) EAR99

Dimensions

Dimensions Dimensions 13 in H x 9.5 in W x 4.6 in D
Height 13 in
Width 9.5 in
Depth 4.6 in
Display Size 3.5 in
Printer Weight 5.42 lb
Weight 5.42 lb

Material Characteristics

Material Characteristics Color Blue

Product Features

Product Features Application Barcode Labeling, Circuit Board Labeling, Facility Identification, General Identification, Healthcare and Hospital Labeling, Laboratory Labeling, Wire and Cable Labeling
Shipped With Battery Yes
Battery mAh Rating 1800 mAh
Battery Weight (metric) 0.75 lb
Battery Weight 340 g
Built-In Label Wizards Flags, Patch Panel, Terminal Block, Wire Wrap
Connectivity Options USB
Cutter Type Between labels or at end of print job, Single Hand Manual Actuate, Straight Cut
Display Type Color LCD Screen
Keyboard Type QWERTY
Memory 200 MB (stores up to 100,000 labels)
Stand Alone Printing PC connected & Stand-alone
Mode of Operation Stand-Alone & Peripheral Modes
Number of Printers in Kit 1
Number of Symbols 500+
Plug Type US
Power Supply Voltage 110 - 245 V
Auto Shut-Off / Power Conserve 10 minutes, User Configurable
Recharge Time 4 hours
Special Characters Quantity Depends on Regional Keypad
User Interface Type Full QWERTY Keyboard
Battery Type Rechargeable NiMH Battery
Label/Media Format Cartridge
Supply Remaining Gauge Yes

Printing Specifications

Printing Specifications Barcode Capability Barcode Capable
Barcode Symbologies - 2D More through Brady WorkStation
Barcode Symbologies - Linear Code 128, Code 39, More through Brady WorkStation
Calibration Required? Automated through Smart Cell
Color Printing Capability Single Color
Font Sizes 4 - 174 pt
Font Styles Arial Alternative Monospaced, Swiss 721
Label Retention Feature No
Maximum Labels per Day 1000
Maximum Print Speed 1.5 in/s
Minimum Label Length 0.236 in
Print Resolution 300 dpi
Minimum Liner Width 0.812 in
Print Technology Thermal Transfer
On Screen Indicators Battery Life, Ribbon and label part number recognition, Ribbon Remaining, Supply Remaining
Device Drop Test & Durability Resistant to 4-foot drops

Compatibility

Compatibility Cartridge Printer Series Bulk Labels (BPTL-), Bulk M71 Series (BM71-, BM71C-), M71 Series (M71-, M71C-, M71EP-, M71FP-, M71FT-)
Compatible Media BM71-, BM71C-, BM71E-, BM71H-, M71-, M71C-, M71D-, M71EP-, M71FP-, M71FT-, PTL-, PTLEP-
Label Material Types FreezerBondz™ Polyester, Heat-shrink Polyolefin, High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Metal-detectable Polyester, Metallized Polyester, Nylon Cloth, Paper, Phosphorescent Polyester, Polyester, Polyester with Polyester Overlaminate, Polyethylene, Polyethylene Foam Laminate Polyester, Polyimide, Polyolefin, Polypropylene, Polyvinylfluoride, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-resistant Metallized Vinyl, Tamper-resistant Vinyl, Vinyl, Vinyl Cloth
Continuous & Die-Cut Materials Supported Continuous and Die-cut
Custom Media Parts Available Yes
Custom Labels Available Yes
Maximum Label/Tape Width 2 in
Maximum Print Width 2 in
Maximum Printed Label Length 40 in
Maximum Liner Width 2.25 in
Software Compatibility Brady Workstation
Languages Available Bulgarian, Czech, Danish, Dutch, English (US), Finnish, French (France), German, Hungarian, Italian, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Slovenian, Spanish (Spain), Swedish

What's Included

What's Included Includes (1) AC Adapter/Battery Charger (M-AC-143110), (1) BMP®71 Printer (BMP71), (1) Drivers CD, (1) Free Brady WorkStation Basic Design Suite Download, (1) Glossy White Polyester Asset and Equipment Tracking Labels (M71-31-423), (1) Halogen Free Printer Ribbon (M71-R6000), (1) Hard Case (M71-HC), (1) Media Adapter (M71-ADAPT-BK), (1) Quick Charger (M71-QC), (1) QuickStart Guide, (1) Rechargeable Battery (M71-BATT), (1) Tutorial and 2 Year Limited Warranty, (1) USB Cable (M-USB-103788), (1) Users Guide
Warranty (North America) 2 Years
Warranty 2 Years

Compliance

Compliance UNSPSC 45101520
Patent Number(s) 5918989, 5951177, 6929415, 7893951, 7999836, 8328442, 8333524, US D635183
California Prop 65 Prop 65WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
RoHS Compliance Status Please contact our CS department for more information
